Cooler Master Elite 110 Mini-ITX Computer Case Review
By Jason Vaught
Manufacturer: Cooler Master Ltd. Inc.
Product Name: Elite 110
Model Number: RC-110-KKN2-AMZ
UPC: 884102025877 EAN: 4719512046876
Price As Tested: $49.99 (Newegg | Amazon | CMStore)
Full Disclosure: The product sample used in this article has been provided by Cooler Master.
The Cooler Master Elite 110 Mini-ITX Computer Case is a compact, cube style case that can handle some full sized desktop components, while maintaining a relatively small footprint. With the ability to handle a ATX sized power supply, and desktop graphic cards up to 210mm (8.26 inches), the Elite 110 is aimed at more than just the niche market. Sporting the ability to hold 4 SSDs or 3 HDDs, storage options are not a problem.
In the past I normally stayed away from small or “tight” cases, mainly because they lacked sufficient space, at least for my tastes. But with the ease and portability of the Mini-ITX platform, cases like the Elite 110 offer little sacrifice in the way of full size performance and features.
Features & Specifications
| Model | RC-110-KKN2-AMZ |
| Color | Midnight Black (black interior) |
| Material | Appearance: polymer front mesh panel Case body: Steel alloy |
| Dimension | 280 x 260 x 208 mm (11.1 x 10.3 x 8.2 in) |
| Weight | 2.7 kg / 5.9 lbs |
| Form Factor | Cube Style / LAN Box / HTPC |
| M/B Type | Mini-ITX |
| 3.5″ Drive Bay | 3.5″ HDD x 3, or 3.5″ HDD x 2 + SSD x 2 or 3.5″ HDD x 1 + SSD x 3 or SSD x 4 |
| I/O | USB 3.0 x 2, Audio In & Out |
| Expansion Slots | 2 |
| Cooling System | Front: 120mm fan x 1 (installed, or convert to 140mm fan x 1) Side: 80x25mm fan x 2 (optional) |
| Power Supply | Top Mount, Standard ATX Form Factor up to 180mm Long |
| Maximum Compatibility | VGA card length: 210mm / 8.3 inch CPU cooler height: 76mm / 3 inch PSU length: 180mm/ 7.1 inch (w/ less cable management) 142mm / 5.6 inch (w/ full cable management) |
| Special Features | Standard ATX PSU Support, 120mm Radiator Support Up to 8.3 inch Long Graphics Card Support |
| Accessories | Accessory Kit |
| Warranty | 2 years |
