NZXT S340 By Razer ATX Case Review
By Tom Jaskulka
Manufacturer: NZXT, Inc.
Product Name: S340 Designed By Razer
Model Number: CA-S340W-RA
UPC: 815671012609
Price As Tested: $99.99 (Amazon | NewEgg)
Full Disclosure: The product sample used in this article has been provided by NZXT.
The Designed By Razer program was started last year to provide a way for manufacturers to collaborate with Razer’s design studio, allowing for products with the Razer branding that may not have existed otherwise. Razer ventured into the gaming laptop market with their Blade series of laptops; so far their desktop components have been limited to peripherals (keyboards/mice/audio). That changed with the introduction of the NZXT H440 | Designed By Razer ATX case. This special edition added some signature Razer elements to the mix – that treatment has now been extended to the H440’s sibling, the NZXT S340. Today, Benchmark Reviews has an opportunity to take a closer look at the S340 “Designed By Razer” edition from NZXT (model CA-S340W-RA). Can a budget-oriented chassis co-exist with a higher price tag? Read on to find out!
Note: Description taken from the NZXT S340 | Designed By Razer page on razerzone.com.
Designed by Razer Case Licensing Program
S340 – Designed by Razer
Razer and NZXT have joined forces to merge Razer’s signature design and unmistakable style with NZXT’s innovative S340 Mid-Tower case. The new custom case features a backlit Triple-Headed Snake logo, tinted window, illuminated LED power button, green underglow, and green USB ports. Are you ready to build your masterpiece?
An all-steel chassis wrapped in a durable steel casing, a grommet-less cable management bar and integrated PSU shroud, all in a compact form factor sporting signature design elements from Razer. The S340 – Designed by Razer is a compact solution that makes it easy to build an ultra-clean Razer themed desktop PC.
Features & Specifications
| Model Number | CA-S340W-RA |
| Drive Bays | External 5.25″: 0 Internal 3.5″: 2+1 Internal 2.5″: 2+1 |
| Cooling System | Front: 2x 140/2x120mm Top: 1x 140/120mm (1 x 120mm FN V2 Fan Included) Rear: 1x 120mm (1 x 120mm FN V2 Fan Included) |
| Filters | Front (Included) Bottom Rear(Included) |
| Radiator Support | Front 2 x 140 or 2 x 120mm Rear 1 x 120mm |
| Clearance | GPU Clearance With Radiator: 334mm GPU Clearance Without Radiator: 364mm CPU Cooler: 161mm Cable Management: Lowest Point – 17mm; Highest Point 168mm |
| Dimensions | 200mm x 445mm x 432mm |
| Material | SECC Steel, ABS Plastic |
| Motherboard Support | Mini-ITX, micro-ATX, ATX |
| Expansion Slots | 7 |
| External Electronics | 1 x Audio/Mic 2x USB 3.0 |
| Product Weight | 7.29 kg |
| UPC | 815671012609 |
| EAN | 5060301692903 |
| USB 3.0 Ports | 2 |
| Warranty | 2 Years |
