Stock Upgrade: Cooler Master Hyper D92 CPU Cooler


<< PREVIOUS            NEXT >>

Stock Upgrade: Cooler Master Hyper D92 CPU Cooler

By Jason Maxfield

Manufacturer: Cooler Master Corporation
Product Name: Hyper D92
Model: RR-HD92-28PK-R1
UPC: 884102026508
Price As Tested: MSRP $44.99

Full Disclosure: The product sample used in this article was provided by Cooler Master

The Cooler Master Hyper D92 is the successor to the Cooler Master Hyper N520 that was introduced back in 2009. The Hyper D92 looks to improve on the Accelerated Cooling System (ACS) design while keeping the price low and compatibility high, with a broad range of cases, RAM, and CPU sockets, including LGA 2011, and FM2+ sockets.

In this article Benchmark Reviews takes a look at the Cooler Master Hyper D92, and we will explore the new features and put it to the test. This article will be geared as more of an upgrade guide than a broad comparison to other CPU coolers currently on the market.


Features & Specifications

Model RR-HD92-28PK-R1
CPU Socket Intel® LGA 2011-3/2011/1366/1156/1155/1150/775
AMD FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2
Dimensions 146.4 x 85 x 126.6 mm(5.7 x 3.3 x 4.9 inch)
Heat Sink Dimensions 146.4 x 128.9 x 96.6 mm (5.7 x 5.1 x 3.8 inch)
Heat Sink Material 4 Direct Contact Heatpipes / Aluminum Fins
Heat Sink Weight 448 g / 0.99 lb
Heat Pipe Dimensions Ø6mm
Fan Dimensions 92 x 92 x 25 mm (3.6 x 3.6 x 1 in)
Fan Speed 800~2,800 RPM (PWM) ± 10%
Fan Air Flow 15.7~54.8 CFM ± 10%
Fan Air Pressure 0.35~4.27 mm H2O ± 10%
Fan Life Expectancy 40,000 hours
Noise Level 18~33 dBA
Bearing Type Rifle Bearing
Connector 4-Pin
Rated Voltage 12 VDC
Rated Current 0.24A + 10% max.
Power Consumption 2.88 W (max)
Fan Weight 74 g / 0.16 lb
Weight 636 g / 1.4 lb

Specifications taken from the manufacturer’s product page.
