Cooler Master Nepton 240M Liquid Radiator Review

By Aidan Moore

Manufacturer: Cooler Master Ltd. Inc.
Product Name: Nepton 240M
Model Number: RL-N24M-20PK-R1
UPC: 884102026744 EAN: 4719512047774
Price As Tested: $129.99 (MSRP)

Full Disclosure: The product sample used in this article has been provided by Cooler Master.

At first glance, the Cooler Master Nepton 240M looks just like any other dual 120mm cooling solution. However, take a closer look at the specifications and you realize that this product is making some substantial performance claims. With a stated typical noise floor of 11 dB(A) and four times greater surface area than the competition, the Cooler Master Nepton 240M should produce some impressive results in comparison to other popular liquid cooling systems.

In this article, Benchmark Reviews looks at the new Cooler Master Nepton 240M all-in-one water cooling system to determine if it’s performance matches the claims. We compare performance for the Nepton 240M against two other popular dual-fan liquid coolers.

Cooler Master Nepton 240M Ortho2

Features

The Nepton 240M is a new 240mm liquid cooler and features Cooler Master’s latest Silencio series fans capable of 1.2mmH20 at only 11dB(A). Cooler Master claims the water-block has been improved with “Jet Impingement Technology”, increasing efficiency and providing a 120 liter per hour flow rate.

  • Extreme Cooling Performance
  • High Efficient 240mm Radiator
  • New Silencio 120 Fans
  • Maintenance Free
  • Durable FEP Tubing
  • Ultrafine Micro Channel

Specifications

Cooler Master published specifications for the Nepton 240M are shown below:

Nepton 240M
CPU Socket Intel LGA 2011 / 1366 / 1150 / 1156 / 1155 / 775AMD Socket FM2+ / FM2 / FM1 / AM3+ / AM3 / AM2+
Pump Dimensions 75 x 69.8 x 49.1 mm ( 3 x 2.7 x 1.9 inch )
Radiator Dimensions 120 x 240 x 27 mm
Radiator Material Aluminum
Fan Dimensions 120 x 120 x 25 mm ( 4.9 x 4.9 x 1 inch )
Fan Speed 1200~2400 RPM (PWM) ± 10%
Fan Airflow 16-76 CFM ± 10%
Fan Air Pressure 0.48-4.8 mmH2O ± 10%
Fan Life Expectancy 160,000 hours
Fan Noise Level 6.5 – 27 dBA
Fan Bearing Type Rifle bearing
Fan Connector 4-Pin
Fan Rated Voltage 12 VDC
Pump Life Expectancy 70,000 hours
Pump Rated Voltage 12VDC
